Product Details
-
- LiFePO4 Battery Modules
-
Energy Storage Battery is multiple of LiFePO4 cylindrical cells assembled and connected with protection board or BMS, and installed in an enclosure to build a complete battery. The battery with customized voltage and power output ( discharging current or kWh ) is ready to integrate any applications.
The information contained in this document is subject to change without prior notice and for reference only.
It should not be used as a basis for product guarantee or warranty.
# Please consult us for more models beyond this list.
Customization
• Customized with voltage and power output (discharging current). Typical options,
• Core cell : 32650, 26650, 22650
• Voltage : 12V, 24V, 48V or higher
• output : 12.8kWh ~ 51.2kWh or higher (regular at 1C, up to 3C-5C)
Ready for assembly
• Modules are ready for assembled with BMS, CAN bus and accessories. A energy storage system is built by multiple modules to provide large scale of supply such as off-grid power supply and UPS system.
Replacement
• Plug & play replacement for maintenance.
